Victron

Victron SmartSolar MPPT 100/30 Solar Charge Controller

Victron SmartSolar MPPT 100/30 Solar Charge Controller

Regular price $200.00 USD
Regular price Sale price $200.00 USD
Sale Sold out

With a worldwide reputation for innovation, reliability, and quality, Netherlands based Vitron has been serving the marine, vehicle, and off-grid markets with their power systems for over 45 years. We're hard-pressed to find anyone that matches Victron for quality.

The Victron BlueSolar MPPT 100/30 is a great choice for controlling up to 440 watts of solar panels at 12 volts, or 880 watts of panels at 24 volts, with a maximum recommended PV open circuit voltage of 90vDC. It automatically selects between 12 and 24 volts on the output.

BlueSolar Features

Besides great build quality and a 5-year warranty, the BlueSolar has a number of unique features.

The Victron MPPT 100/30 can be connected right out of the box, and a rotary switch lets you choose between 8 preset battery type profiles. More extensive configuration and monitoring is possible with:

• The Victron Bluetooth Dongle and the free app on your smartphone, tablet, or Mac, for graphical presentation of real-time and historical data. Setup can also be done via the app.

• The Victron Color Control GX Panel, which can also connect to Victron battery chargers, inverters, and battery monitors.

• The new MPPT Control remote, a dedicated monitor/control for all current Victron MPPT controllers with a VE.Direct port.

• The VE.Direct cable can connect Victron MPPT controllers with VE.Direct ports to a Windows PC (more details here).

Outstanding maximum efficiency exceeds 98%, with no cooling fan needed. Full output current up to 40°C (104°F). Internal temperature sensor compensates absorption and float charge voltages for temperature. Electronic components are resin encapsulated to protect against the elements.

For more information, see the Victron BlueSolar User's Manual, Data Sheet, or MPPT Overview.

Model Victron BlueSolar MPPT 100/30
Battery voltage 12 / 24 volt auto select
Rated charge current 30A
Maximum PV power, 12V (a,b) 440 W
Maximum PV power, 24V (a,b) 880 W
Max. PV short circuit current 30A
Maximum PV open circuit voltage 100V
Peak efficiency 98%
Self consumption 10mA
Charge voltage 'absorption' Adjustable, default = 14.4V / 28.8V
Charge voltage 'float' Adjustable, default = 13.8V / 27.6V
Charge algorithm Multi-stage adaptive
Temperature compensation -16 mV / °C resp. -32 mV / °C
Operating temperature -30 to +60°C (full rated output up to 40°C)
Humidity 95%, Non-condensing
Data communication port VE.Direct
Colour Blue (RAL 5012)
Power terminals 13 mm² / #6 AWG
Protection category IP43 (electronic components), IP22 (connection area)
Weight 1.3 kg (2.9 lb)
Dimensions (h x w x d) 130 x 186 x 70 mm (5.1 x 3.4 x 2.6 inch)
