Sterling

Sterling Power Waterproof DC-DC Chargers

Sterling Power Waterproof DC-DC Chargers

Regular price $378.00 USD
Regular price Sale price $378.00 USD
Sale Sold out
Amps

The waterproof ProBatt-C is a unique product from Sterling Power that was designed to resolve a problem that is common on boats that need to charge a house bank when underway, or any separate battery bank that is remote or of a different voltage from the main charging system. RVs can also benefit from these chargers to keep their house bank topped up when a protected installation area is not available.

The Sterling Power ProBatt-C DC-DC Charger is a quality multi-stage charger that uses the energy coming into a battery from any power source, and uses it to charge another battery bank. This has a number of advantages:

  • Each battery bank receives the correct charge current, depending on its state of charge.
  • The voltage drop induced by a long cable run to a remote or bow-mounted battery is corrected for (these batteries tend to not be fully charged otherwise).
  • Alternator output is maximized, minimizing engine run time for battery charging.
  • Remote batteries are properly maintained and de-sulphated, extending battery life.
  • It is possible to charge batteries when voltages differ from the primary system.

An in-depth look:

This on-board solution is able to provide a 4-stage charging profile to your batteries without being plugged into shore power. The Sterling Power ProBatt-C induces the alternator into working at maximum potential. The surplus power (power left over after charging the primary battery) is converted into a higher voltage and is used to charge your auxiliary battery bank faster (dependent on alternator, typically 5 times faster) than using just a standard alternator!

As the ProBatt-C does not connect to the alternator there are neither ECU nor warranty issues as there is no voltage rise on the engine management system. This system is designed to use only the surplus power - the power required to run the primary vehicle or vessel systems are not affected. The surplus power is converted into a higher voltage and is used to charge a secondary battery bank using a digitally-controlled programmable 4-step charging curve whose unit is also totally isolated; i.e. the starter battery cannot discharge through this system.

The ProBatt-C monitors the engine start battery. This unit will not start until the battery voltage exceeds about 13 volts, then it waits for 2.5 min. to ensure that some charge is replaced quickly into the engine start battery. After that, it pulls the engine battery down to no less than 13 volts, which enables the engine battery to still receive a small charge and ensures the alternator works at its full potential. To further ensure the engine battery is charged, every 20 min. the unit stops for about 3 min. to ensure the engine battery is topped off. The unit takes the 13 volts into the control box and then boosts this up to 14.8 volts (or the appropriate voltage for the chosen battery type), in order to fast charge the other set(s) of batteries. After a period of time, calculated by the software, when the auxiliary batteries are full, the system will float the batteries at 14 volts, but always ensuring the engine battery comes first. Other features included in this system are an alternator and a battery temp sensor. There is also a remote battery sensor and a fully automatic sleep sensor, which switches the unit off when the engine has stopped. A remote panel is available as an optional extra.

Input amps (12v) 60A / 120A model-dependent
Size (LxWxH) 6"x4.5"x4.9" / 6.7"x5.2"x5.0" model-dependent
Weight 6.6 / 7.5lbs model-dependent
